LifeSmart Nature

All-in-one smart control panel

LifeSmart Nature is a Metal frame all-in-one smart control center. It’s designed with a Colorful UI, 4 customizable physical scene buttons, and a 10.25 “high-definition touch screen to enjoy wonderful HCI (human-computer interaction). It could control smart devices like lighting switches, dimmer, door locks, curtain motors, air conditioners, SONOS, cameras… It’s also an intercom, compatible with Akuvox and Dahua door stations.

Categories: ,

FEATURES

  • Metal frame, more advanced and fuller of technology sense
  • Colorful UI and quick control bar for the ultimate operation experience
  • Customizable physical keypads to quickly switch scenes
  • No limit to the number of devices that can be controlled on the panel
  • Support video Intercom, compatible with Akuvox, Dahua door stations

SPECIFICATION

 General
Model Number LS148
Installation In-wall concealed with pre-embedded back box(standard )
Operating Temperature -5~45℃
Operating Humidity 5~90%
Network Wi-Fi 2.4GHz/ Ethernet
Power Consumption <20W
Interface Live/Neutral/Earth wire in;  Ethernet RJ45;  HDMI in;  USB
Button Customizable scene-switch button×4 Power button
Screen 10.25 inch touch screen
Resolution 1920×720
CPU 4 Core ARM
Power Supply AC 100-240V 50/60Hz
RAM 2GB
Operating System Android 5.1
Bluetooth Yes (Bluetooth 4.2)
Speaker Yes
Microphone Yes
 Construction
Color
Matte grey
Dimension Exposed dimension: 342*122*16mm

Backbox dimension: 335*114*70mm
Weight 1260g(panel only)
Casing Aircraft aluminum
